  • Low Pressure Switch PS-LA14_1
  • Low Pressure Switch PS-LA14_2

Low Pressure Switch PS-LA14

| See more "Air,Gas Pressure Switch" Products

product category: Air,Gas Pressure Switch
Model: PS-LA14
Viewed:

OnLine Service :
Print this page E-mail Us
Live Messenger Skype Online

Product Detail
Low Pressure Switch PS-LA14


The Low Pressure Switch PS-LA14 offers the same proven compression spring and
precision snap action electrical switch as the other popular and widely used pressure
switches.
The Low Pressure Switch PS-LA14 is designed specifically to variable applications
with wide adjusting set point from 5kPa to 100kPa, as well as to hold tight set point
tolerances throughout a wide temperature range.


SPDT, SPST electrical loads: 5A @ 125/250 VAC
10A @ 125/250 VAC
16A @ 125/250 VAC
Switching circuits SPDT, SPST-NO, SPST-NC
Electrical terminals: #187 (3/16”) 4.8x0.5 mm quick connect
#250 (1/4”) 6.3x0.8 mm quick connect
Set points Tolerance: +/-5% ~ +/-10% of set point.
Overpressure rating: 0.6MPa
Ambient temperature range -25 + 85℃
Sampling line connector: 12.7 mm snap connector for 10mm ID tubing; 1/4” NPT connecting; M10*1.0 mete thread connecting; other types of connector on customer demands.
Sampling Medium Air or combusted products.
Dimensions For typical dimensions
Mounting Orientation Diaphragm must be vertical (Horizontal
optional).
Materials: Diaphragm: Post-cured silicone, RTI>150 deg C.
Pressure housing: Thermo-plastics with RTI>130
Snap action switch housing: Thermo-plastics with RTI>120 deg C, UL94-V0.
Product Life: Mechanical: 200,000 cycles.
Electrical: 100,000 cycles.
Approvals CE, CQC
